CDLC1000B
1M Cooling Dual lane Linking Conveyor - Cooling system.(1m long 8 fans or specify) - 2 segments - Belt - Motorise width adjustment function - Dust cover - For Follow me, IPC Hermes, Ethernet communications, etc .... , need to add SMARTBOX : MSTECH Produt " motorise Automatic width adjustment function Max 250mm PCB width - Pass / Auto Mode - ESD cover with interlock
Stainless steel lead screw width adjustment
Ergonomically designed ESD table
Independent Speed Control for each segment
Using the quality stepper motor and drivers to transfer the boards
Stepper motor
SMEMA Compatible
Conveyor width adjustment : HMI programming (automatic)
High end power switchs
Speed controller
ESD cover with interlock
Conveyor: ESD flat belts
Panasonic PLC control+ Sensor
Working mode: Inspection mode , Pass through
Heavy duty design for machine stable
Top component height 50mm ; Bottom component height: 30mm
Conveyor length : 1000MM, 1 segment
PCB weights: 3kg per PCS
PCB width: 50*50 to 500*460 mm (L*W)
Machine dimension: (L)500mm*(W)950*(H)930MM
Power: AC220V, 50/60 HZ, 1 phase
PCB Convey Direction: L to R, Front rail fixed
Conveyor Height: 900+/-50mm
Conveyor Speed: 1-12 m/min adjustable
Package gross weight: 105kg
