Wave Soldering Oven - PCBmax : 50*450 mm

MSTECH Europe
MTU-450

MTU-450 Wave Soldering Machine
The MTU-450 is a high-capacity wave soldering machine designed for wide PCB applications, delivering precise, stable, and efficient soldering performance. With advanced dual-wave technology, intelligent control systems, and robust construction, it ensures consistent high-quality results for demanding production environments.
Applications
Ideal for large-format and high-density PCB assembly, including:

Consumer electronics
Automotive electronics
Industrial and power electronics
EMS and high-volume production lines

Key Features

Extended PCB handling up to 450 mm width
Dual wave system: laminar + dancer for superior solder quality
High-precision temperature control (±1°C)
4-zone preheating system (1800 mm) with hot air convection
PLC + PC control system with alarms, automation, and scheduling
Automatic flux spraying system with intelligent detection and adjustable flow
Advanced flux management with recycling and exhaust filtration system
Automatic finger cleaning system with recyclable alcohol solution
Energy-efficient matrix heating (up to 95%)
Robust, fully enclosed design for safety and ease of maintenance
SMEMA interface for seamless production line integration
