Wave Soldering Oven-PCBmax : 50*500 mm

MSTECH Europe,
MTU-500

The MTU-500 is a large-format, high-capacity wave soldering machine designed for demanding PCB production environments. Built for maximum throughput and precision, it combines advanced dual-wave technology, intelligent automation, and efficient thermal management to deliver excellent soldering quality on complex and wide PCBs.
Applications
Ideal for extra-wide and complex PCB assemblies, including:

Automotive and power electronics
Industrial equipment and control systems
Large consumer electronics boards
EMS high-volume production lines

Key Features

Extended PCB capacity up to 500 mm width for large-format boards
Dual wave system: laminar (first) + dancer (second) for optimal soldering results
High-precision temperature control (±1°C)
4-zone preheating system (1800 mm) with hot air convection
Advanced PLC + PC control system with intelligent automation and alarms
Automatic flux spraying system with detection and adjustable flow
Enhanced flux management system with recycling, air curtain, and filtration
Automatic finger cleaning system with recyclable alcohol solution
Energy-efficient matrix heating (up to 95%)
Robust enclosed structure for durability, safety, and easy maintenance
SMEMA interface for seamless integration into production lines
