TestStation LX2

Configurable up to 15,360 Test Points

TestStation LX2 is Teradyne’s largest pin count in-circuit test system. Configurable up to 15,360 pins, TestStation LX2 utilizes the new UltraPin II 128HD pin card for testing large, complex, and heavily-integrated printed circuit board assemblies.

TestStation LX2 features:

  • Configurable from 256 to 15,360 pins
  • Capable of testing large, complex, and heavily-integrated PCBs
  • Safe, accurate, and reliable electrical test
  • Exceptional diagnostic accuracy
  • Designed for fast test throughput

The TestStation LX2 test system supports all the standard and optional features of the TestStation platform, but is unique in the following ways:

  • Highest capacity in-circuit test solution in Teradyne’s TestStation family
  • Configurable with up to 15,360 pins
  • Equipped with built-in features for testing large, complex, and heavily-integrated PCBs
  • Supports up to 30 pin card slots
  • Configurable with 128L, 128HD, and 124 hybrid pin cards to optimize tester pin counts and compatibility with previous TestStation LX systems
  • The High Speed Digital Subsystem and Clock/Sync/Trigger (CST) features of the TestStation platform come standard with the TestStation LX2
